RC-5K
Features:
1. Low start up speed, high wind energy utilization
2. Amazingly quiet operation with minimal vibration
3. Easy installation, tube or flange connection optional
4. New art of precision injection molding blades with aerodynamic shape and structure, high efficiency.
5. Casting Carbon Steel generator body, with 2 bearings swivel makes generator stronger.
6. Patented AC PMG with special stator, effectively reduce torque, ensure excellent performance.
7. Anti-rust & anti-corrosion, maintenance-free
Specification: RC-5K
| Model | RC-5K |
|---|---|
| Rated Output | 5KW |
| Peak Output | 7KW |
| Rated Voltage | 48/96/120/220V/380V AC |
| Start-up Wind Speed | 2.5 m/s |
| Cut-in Wind Speed | 3.5m/s |
| Rated Wind speed | 12m/s |
| Survival Max. wind | 45m/s |
| Number of Blades | 3 |
| Rotor Diameter | 4.7m |
| Swept Area | 17.34㎡ |
| Blade Material | fiberglass reinforced composite |
| Generator Type | Brushless 3-phase PMA with high performance Neodymium Magnets |
| Generator case | Casting Carbon steel |
| Controller Type | PWM |
| Over speed control | Automatically adjust windward direction&Tail &tail fold up |
| Net Weight | 215kg |
| Tower Connector | Flange |
| Flange Size * | DN125 |
| Tower Type * | Guy Cable Tower |
| Tower Size * | 3mX3, 140-4mm |
| Working Temp. range | from -40°C to 60°C |
| Product Life | 15 years |
| Warranty | 1 years |
| Applications | on/off-grid solar & wind hybrid system etc. |
| Measurement | Generator: 0.9*0.52*0.45m / Blades and tail rod: 2.3*0.3*0.4m |
| Gross Weight | 245kg |
